1/3" 2.8mm F2.5 M12*0.5 mount 140degree wide angle MTV board lens

1/3" 2.8mm F2.5 M12*0.5 mount 140degree wide angle MTV board lens

1/3" 2.8mm F2.5 M12*0.5 mount 140degree wide angle MTV board lens

Product Details:

Place of Origin:	China
Brand Name:	CCOM LENS
Model Number:	13028

Payment & Shipping Terms:

Minimum Order Quantity:	100pcs
Packaging Details:	Standard
Delivery Time:	2-7 work days
Payment Terms:	T/T, Western Union, Moneygram, Paypal
Supply Ability:	Samples available

Contact Now

Detailed Product Description

High Light:

wide angle lens

,

2.8mm MTV lens

,

M12x0.5 Board Lens

1/3" 2.8mm wide angle lens, 140°, 1/3" CCD, F2.5, M12*0.5 mount MTV board lens, 4G+1IR

Model: 13028

Image format: 1/3” CCD

Focal length: 2.8mm

F.O.V.(D*H*V): 140°*112°*84°

B.F.L.: 5.05mm

F.B.L.: 3.75mm

Aperture: 2.5

Distortion: <-30%

Mount: M12*0.5

Dimension(mm): Φ14*15.75

Lens component: 4G+1IR (IR 650nm)
