1/3" 2.3mm 3Megapixel 140degree M8*0.5P mount wide angle lens

1/3" 2.3mm 3Megapixel 140degree M8*0.5P mount wide angle lens

1/3" 2.3mm 3Megapixel 140degree M8*0.5P mount wide angle lens

Product Details:

Place of Origin: China
Brand Name: CCOM LENS
Model Number: 13023MPF-M8

Payment & Shipping Terms:

Minimum Order Quantity: 100pcs
Packaging Details: Standard
Delivery Time: 2-7 work days
Payment Terms: T/T, Western Union, Moneygram, Paypal
Supply Ability: Samples available
Minimum Order Quantity: 100pcs
Contact Now
Detailed Product Description

1/3" 3Megapixel wide angle lens for Automobile data recorder, F2.8, 2.3mm, 140degree, M8*0.5P mount lens


Model 13023MPF-M8
IMAGE FORMAT 1/3"
MAX IMAGE CIRCLE Ø 6.4mm
FOCAL LENGTH 2.3mm
F.O.V (D*H*V)
1/3” AR0330: 129°*105°*55°
1/3” OV5653: 125°*91°*66°
1/4” OV5640: 90°*72°*52°
DISTORTION <-37%/-28%/-17.5%
RELATIVE ILLUMIMATION >95%/95%/96%
CRA <15.6°/15.4°/12.4°
APERTURE F2.8
RESOLUTION 3MP
MOUNT M8XP0.5
IRIS Fixed
B.F.L. 5.09mm
F.B.L. 4.49mm
DIMENSION Φ(11±0.1)×(10.11±0.2)mm
LENS COMPOMENT 5G+IR
