1/3" 2.25mm 5Megapixel S-mount wide-angle cctv lens for AR0330 & 1/4" sensors

1/3" 2.25mm 5Megapixel S-mount wide-angle cctv lens for AR0330 & 1/4" sensors

    • 1/3" 2.25mm 5Megapixel S-mount wide-angle cctv lens for AR0330 & 1/4" sensors
    • 1/3" 2.25mm 5Megapixel S-mount wide-angle cctv lens for AR0330 & 1/4" sensors
    • 1/3" 2.25mm 5Megapixel S-mount wide-angle cctv lens for AR0330 & 1/4" sensors
    • 1/3" 2.25mm 5Megapixel S-mount wide-angle cctv lens for AR0330 & 1/4" sensors

    Product Details:

    Place of Origin: China
    Brand Name: CCOM LENS
    Model Number: 130225MPF-C1

    Payment & Shipping Terms:

    Minimum Order Quantity: 100pcs
    Packaging Details: Standard
    Delivery Time: 2-7 work days
    Payment Terms: T/T, Western Union, Moneygram, Paypal
    Supply Ability: Samples available
    Minimum Order Quantity: 100pcs
    Contact Now
    Detailed Product Description

    1/3" 2.25mm 5Megapixel S-mount 160degree wide-angle cctv lens for AR0330 & 1/4" sensors


    MODEL: 130225MPF-C1
    IMAGE FORMAT: 1/3"
    FOCAL LENGTH(mm): 2.25
    F.O.V.(D*H*V): 1/3"(AR0330) 160°*132°*75°; 1/4": 120°*90°*60°
    RESOLUTION: 5MP
    OPTICAL DISTORTION: 1/3" <13%; 1/4" <25%
    APERTURE: F2.2
    MOUNT(mm):M12x0.5
    IRIS: Fixed
    F.B.L.(mm): 3.75
    B.F.L.(mm): 4.74
    T.T.L.(mm): 16.86
    LENS COMPOMEMT: 6G+IR(400-700nm)

    Tag:

    lens supplier,

    CCTV lens,

    wide angle lens
